200-3000-2-5-2-36-ST8 –PT40-3000psig-1-5-2-36-ST8 new cross over number Pressure Transmitter, 0 psig to 3000 psig, 0.25% Accuracy (BFSL), 0 Vdc to 10 Vdc Output, 1/4 NPT Male, Integral Cable 36 in, 0.8 mm SS Threaded Orifice
Original price was: $568.50.$448.52Current price is: $448.52.
5 in stock
Pressure Transmitter, 0 psig to 3000 psig, 0.25% Accuracy (BFSL), 0 Vdc to 10 Vdc Output, 1/4 NPT Male, Integral Cable 36 in, 0.8 mm SS Threaded Orifice
NOSHOK 100, 200, 300 and 615 Series transmitters are replaced with the new PT Series, an enhanced and expanded portfolio of fixed range general purpose pressure transmitters that provides significant performance improvements and options.
High Accuracy Fixed Range Pressure Transmitter, 0 to 3000 psi gauge, ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions, 0 Vdc to 10 Vdc, 3-wire, 1/4 NPT male, integral cable 3 ft, integral orifice
.
| SPECIFICATIONS | ||
| Output signals | 4 mA to 20 mA, 2-wire; 0 Vdc to 5 Vdc, 0 Vdc to 10 Vdc, 1 Vdc to 5 Vdc,3-wire | |
| Pressure ranges | Gauge, compound, absolute and vacuum ranges from 2 psi to 15,000 psi | |
| Accuracy* | ±0.25% of span, optional ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions | |
| Adjustment | ± 10% full scale for zero and span | |
| Response time | Less than 1 ms (between 10% and 90% full scale) | |
| Service life | >100 million load cycles | |
| Temperature ranges* | Compensated: Media: Ambient: Storage: |
32 °F to 176 °F (0 °C to 80 °C) -22 °F to 212 °F (-30 °C to 100 °C) -22 °F to 185 °F (-30 °C to 85 °C) -40 °F to 212 °F (-40 °C to 100 °C) |
| Power requirement* | 10 Vdc to 30 Vdc: 14 Vdc to 30 Vdc: |
4 mA to 20 mA, 2-wire 1 Vdc to 5 Vdc, 3-wire 0 Vdc to 5 Vdc, 3-wire 0 Vdc to 10 Vd, 3-wire |
| Proof pressure | <300 psi: 300 – 10,000 psi: >10,000 psi: |
3 times full scale 2 times full scale 1.5 times full scale |
| Burst pressure | <300 psi: 300 – 10,000 psi: >10,000 psi: |
5 times full scale 4 times full scale 3 times full scale |
| Measuring element | 316 Stainless Steel: 13-8PH Stainless Steel: |
Vacuum through 300 psi ≥500 psi |
| Process connection | 316 Stainless Steel | |
| Housing material | 316 Stainless Steel | |
| Environmental rating | IP65: DIN EN 175301-803 Form C, DIN EN 175301-803 Form A IP67: 4-pin Bayonet, 6-pin Bayonet, 1/2″ NPT conduit, M12 x 1 (4-pin), Integral cable |
|
| Electromagnetic rating | CE compliant to EMC norm EN 61326:2014/A1:1998 RFI, EMI and ESD protection |
|
| Electrical protection | Reverse polarity, overvoltage and short circuit protection | |
| Shock | 1,000 g’s according to IEC 60068-2-27 | |
| Vibration | 20 g’s according to IEC 60068-2-6 | |
| Weight | Approximately 7.5 oz. | |
*See user manual for detailed specifications
Description
Pressure Transmitter, 0 psig to 3000 psig, 0.25% Accuracy (BFSL), 0 Vdc to 10 Vdc Output, 1/4 NPT Male, Integral Cable 36 in, 0.8 mm SS Threaded Orifice
NOSHOK 100, 200, 300 and 615 Series transmitters are replaced with the new PT Series, an enhanced and expanded portfolio of fixed range general purpose pressure transmitters that provides significant performance improvements and options.
High Accuracy Fixed Range Pressure Transmitter, 0 to 3000 psi gauge, ±0.25% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions, 0 Vdc to 10 Vdc, 3-wire, 1/4 NPT male, integral cable 3 ft, integral orifice
.
| SPECIFICATIONS | ||
| Output signals | 4 mA to 20 mA, 2-wire; 0 Vdc to 5 Vdc, 0 Vdc to 10 Vdc, 1 Vdc to 5 Vdc,3-wire | |
| Pressure ranges | Gauge, compound, absolute and vacuum ranges from 2 psi to 15,000 psi | |
| Accuracy* | ±0.25% of span, optional ±0.125% of span, non-linearity best fit straight line per IEC 61298-2 at reference conditions | |
| Adjustment | ± 10% full scale for zero and span | |
| Response time | Less than 1 ms (between 10% and 90% full scale) | |
| Service life | >100 million load cycles | |
| Temperature ranges* | Compensated: Media: Ambient: Storage: |
32 °F to 176 °F (0 °C to 80 °C) -22 °F to 212 °F (-30 °C to 100 °C) -22 °F to 185 °F (-30 °C to 85 °C) -40 °F to 212 °F (-40 °C to 100 °C) |
| Power requirement* | 10 Vdc to 30 Vdc: 14 Vdc to 30 Vdc: |
4 mA to 20 mA, 2-wire 1 Vdc to 5 Vdc, 3-wire 0 Vdc to 5 Vdc, 3-wire 0 Vdc to 10 Vd, 3-wire |
| Proof pressure | <300 psi: 300 – 10,000 psi: >10,000 psi: |
3 times full scale 2 times full scale 1.5 times full scale |
| Burst pressure | <300 psi: 300 – 10,000 psi: >10,000 psi: |
5 times full scale 4 times full scale 3 times full scale |
| Measuring element | 316 Stainless Steel: 13-8PH Stainless Steel: |
Vacuum through 300 psi ≥500 psi |
| Process connection | 316 Stainless Steel | |
| Housing material | 316 Stainless Steel | |
| Environmental rating | IP65: DIN EN 175301-803 Form C, DIN EN 175301-803 Form A IP67: 4-pin Bayonet, 6-pin Bayonet, 1/2″ NPT conduit, M12 x 1 (4-pin), Integral cable |
|
| Electromagnetic rating | CE compliant to EMC norm EN 61326:2014/A1:1998 RFI, EMI and ESD protection |
|
| Electrical protection | Reverse polarity, overvoltage and short circuit protection | |
| Shock | 1,000 g’s according to IEC 60068-2-27 | |
| Vibration | 20 g’s according to IEC 60068-2-6 | |
| Weight | Approximately 7.5 oz. | |
*See user manual for detailed specifications
